TekTone NC365B Tek-CARE Paging Transmitter

TekTone NC365B Tek-CARE Paging Transmitter

Vendor
TekTone
Regular price
$5,122.50
Sale price
$3,585.75
Shipping calculated at checkout.
Quantity must be 1 or more

DESCRIPTION

The NC365B Paging Transmitter receives alphanumeric messages and patient call information via serial interface and transmits the information directly to pagers. Information is sent to the transmitter at 9600 baud to minimize bottlenecks. Call type and location are determined by the system supplying information to the transmitter. The NC365B Paging Transmitter is pre-programmed for use with TekTone® systems for simplified plug-and-play setup.

The system’s range depends upon the site and the transmitter’s location. To determine the exact coverage, conduct a site survey. Under ideal conditions, the NC365B Paging Transmitter’s range is approximately one mile. The unit includes a ¼-wave BNC-terminated antenna to provide coverage that meets most requirements.

SPECIFICATIONS

  • Dimensions: 7.48" × 12.99" × 2.76" (190 mm × 330 mm × 70 mm)
  • Clearance: 7.87" (200 mm) minimum clearance on all sides
  • Ports: Scope protocol RS232 serial DB9 COMP2 protocol RS232 serial DB9 8 dry contact inputs configured as Normally Open (#8 is preprogrammed to send RANGE TEST to CAP code 400 using included dummy plug.)
  • Housing: Surface mounted
  • Frequency: 457.55 MHz
  • Channel Spacing: 12.5 KHz
  • Adjacent Channel: Better than 200nW @ 4.5 KHz deviation
  • Baud Rate:
    • 9600 serial input
    • 1200 transmit
  • Power:
    • 115 VAC 0.8A, 50/60 Hz input
    • 2 Watt output
    • Consumption less than 50mA
    • standby; up to 2.4A transmit
    • 13.8 Volts DC operating voltage

WARRANTY

One (1) year manufacturer's warranty plus an exclusive one (1) year BuyTekTone.com extended manufacturer's warranty.*
