TRANSFORMER FEATURES
TekTone’s SS102A and SS106 Class 2 Transformers offer compact, easy-to-install low voltage AC power sources for use with various TekTone® intercom systems. Both transformers are UL® Listed Class 2 transformers and will safely take themselves offline when overheated.
The transformers are constructed for easy surface installation or in a standard 1/2" knockout, and may be used in plastic or metal boxes. Primary wire connections are made using the pre-stripped pigtails and ground wire; secondary connections are made using screw terminals.
ELECTRIC DOOR OPENER FEATURES
TekTone’s PO001 Electric Door Opener is for use in unlocking and locking doors from a variety of TekTone remote stations. The door opener can be installed in place of the door lock, or on a door jamb with various door lock sets.
The PO001 is a normally locked type with heavy duty coils, and operates on 8-16 VAC or 3-6 VDC. The unit features a flat face with satin zinc finish and solid brass locking latch for long wear. The PO001 is reversible for mortise-type locks and latches up to 1/2" width and throw, and is ideal for most narrow jamb mortise-type installations. Depending on the specific job requirements, the PO001 can be reversed for right or left-hand door installation.
SPECIFICATIONS
- SS102A 120 VAC primary, 16 VAC 10 VA secondary
- SS106
- 120 VAC primary, 8 VAC 20 VA
- 16/24 VAC 30 VA secondary
DIMENSIONS
- Faceplate: 1.25" × 5.875" (31.8 mm × 149 mm)
- Case width: 0.9375" (24 mm)
- Case depth: 1.4375" (37mm)
- Latch opening: 1.375" (35 mm)
WARRANTY
One (1) year manufacturer's warranty plus an exclusive one (1) year BuyTekTone.com extended manufacturer's warranty.*
